150Mbps Wireless ADSL2/2+ Modem Router
The Edimax AR-7188WnA/B is a high performance router that provides full ADSL2+ capability and superb reliability as a cost-effective networking solution for homes and small businesses. Compatible with the next generation wireless standard 802.11n, and with advanced MIMO technology, the AR-7188WnA/B provides up to 3 times better data transmission rates (up to 150Mbps) .
Wi-Fi Protected Setup (WPS)
Wi-Fi Protected Setup is a quick and convenient method of establishing wireless connections between compatible devices. Set up a wireless network in less than a minute with just a couple of clicks of a button or easily add new Wi-Fi devices to an existing network.
Built-in ADSL2/2+ Modem and Annex M Technology
Share any ADSL, ADSL2 or ADSL2+ Internet connection to all wired and wireless network clients (up to 253 clients), and support G.992.5 ADSL2+ Annex M Technology to improve downstream speeds up to 24Mbps and upstream speeds up to 1Mbps.
Multi-language Setup Wizard
A unique and convenient multi-language setup wizard is provided on the included CD-ROM. Select your language and follow a few simple steps to setup the router and configure the Internet connection, password, SSID and wireless security.
Virtual Server and DMZ
Built-in virtual server and DMZ functions are featured to provide maximum security for applications which require open ports such as online games, VoIP phones or web servers.
SPECS
Hardware Interface
•1 x RJ-11 WAN-port
•4 x RJ-45 Fast Ethernet LAN ports
1 x Reset button for factory default settings
•1 x WPS button
•1 x WLAN button
•1 x 5dBi antenna
•Power on/off button
•LED indicators: power, ADSL, LAN 1–4, WLAN, WPS
Management
Web based configuration
•Web page/XMODEM/FTP/TFTP firmware upgrade
•Command-line interface via serial port, telnet or SSH
•Universal Plug and Play (UPnP)
•WAN Management Protocol (TR-069)
•Date/time update from SNTP time server
Output Power
•11n: 14±1.5dBm
•11g: 15±1.5dBm
•11b: 16±1.5dBm
ADSL Features
Annex A, B,I, J, L & M
•ANSI T1.413i2
•ITU G.992.1 (G.dmt), ITU G.992.2 (G.lite)
•ITU G.992.3 ADSL2 (G.dmt.bis), ITU G.992.4 (G.lite.bis)
•ITU G.992.5 (G.dmt.bisplus), ITU G.994.1 (G.hs)
•ITU G.995.1, ITU G.996.1, ITU G.997.1
•Power saving mode, L3 to L0 initialization
•Supports multiple PVCs
•Supports traffic shaping (ATM QoS) UBR, CBR, VBR-rt, VBR-nrt
•Supports OAM F4/F5 loop-back, AIS, and RDI OAM cells
•UNI 3.1/4.0 permanent virtual circuits
Wireless Features
Compatible with IEEE 802.11b,IEEE 802.11g and IEEE 802.11n
•Supports auto channeling
•1T1R mode with 150Mbps PHY rate for both transmitting and receiving
•Legacy and high throughput modes
•20MHz/40MHz Bandwidth
•Supports 64/128-bit WEP, 802.1x, WPA and WPA2 wireless security
•Multiple BSSID support
•Wireless frequency range: 2400–2483 MHz ISM band
•802.1x authentication
Routing Features
•Routing (TCP/IP/UDP/ARP/ICMP)
•802.1D MAC Bridge
•RIP v1 (RFC1058), RIP v2 (RFC1723)
•IGMP Snooping (V1/V2/V3)
•IGMP Proxy (V1/V2)
•VLSM (RFC1878)
•RFC 1877 PPP IPCP Extensions for Name Server Address
•RFC 1877 PPP IPCP Extensions for Name Server Addresses (limited to DNS addresses unless the device supports NetBIOS)
•RFC 0791 IP Fragmentation
•IETF RFC 0919, IETF RFC 0922, IETF RFC 2644 IP Broadcast
Frequency & Modulation
2400–2484 MHz
•802.11b: CCK, DQPSK, DBPSK
•802.11g: 64QAM, 16QAM, QPSK, BPSK, DSSS
•802.11n: 64QAM, 16QAM, QPSK, BPSK
Humidity & Temperature
Operating: 0 to 40°C
•Storage: -40 to 70°C
•Operating: 10 to 90% RH (Non-condensing)
•Storage: 5 to 95% RH (Non-condensing)
Memory
•2 MB NOR Flash
•8 MB SDRAM
Dimension & Power
•115 x 110 x 28 mm
•12V DC, 0.5A
